Fmworld 454K Agricultural Farm Mini Wheel Tractor with 45HP

Basic Info

Model NO.	FMWORLD-454K
Emission Standard	Cn Stage II
Fuel	Gas / Diesel
Service Life	6-10 Years
Size	Medium
Color	Black and Red
Condition	New
Power	45HP
Transmission	Shuttle 8f+8r
Grand Clearance	440mm
Tires(F/R)	8.3-20/12.4-28 Pr-1, Other Sizes Are Optional
Ballast Weight Front/Rear	108/90kg
Mini Operation Weight	1950kg
Transport Package	Container
Specification	3600*1572*2650mm
Trademark	FM World
Origin	China
HS Code	87019210
Production Capacity	100000 Sets Per Year

Product Description

Description

The latest version of WD454K agricultural tractor equipped with high quality 45 hp engine which brings stronger power but lower fuel consumption. It is easier to operate as the new 8F+8R shuttle transmission upgraded. It always be a perfect match for puddy field thanks for our engineers designed axles with excellent sealing performance. The expected lifespan is longer as well because most of its accessories like bearings were upgraded.

Specification

Model		WD454K
Structure		4*4
Engine	Engine [email protected](HP)	[email protected]
	Engine Type	4 Clinders,Inline,Water-Cooling
	Battery	12V
	Fuel Tank Capacity(L)	70
	Air Cleaner	Dry
Transmission	Gears	Shuttle 8F+8R
	Brake	Mechanical
PTO System	Direction of Turning	Clockwise, viewed from tractor rear
	Diameter of PTO Shaft(mm)	35
	PTO Speeds(rpm)	540/760
Hydraulics System	Type	Category I & 3 point hitch
	Control System	Position, draft

Details of Product

FM World 454K increased the volumn of its fuel tank from 50L to 70L which brings a better fuel range. Tiredness happened during long-time working could be effectively alleviated as the seat designed for comfortable use and soft materials are applied.The flat ground and clear gear also helps. Another improved function is the new 454K equipped with South-eastern asia r1-t tires. It strengthens the performance of tractors in paddy field.

Oil bath filter is a better choice for muddy and humid environment while air filter is prone to be polluted by water. It effectively reduce the times of changing and fixing filter. New translucent shell of diesel filter is a driver-oriented design. Driver can obeserve the situation of oil everyday without any effort. Paddy field front axle has been designed for paddy field and has been proved by our customers in last decade. Good sealing performance. Now a high quality water proof front axle has been one character of FM world tractors in all series.

Assembly Line of Tractor

FM World Agricutlrual Machinery is a big-scale farming machine manufacturer in China, which belongs to World Group. Advantages in capital and technology make us a great supply chain. We produce 80% of accessories of our tractor by ourselves, from a single bearing to the whole tractor. We can control our products quality from the start to the end owing to this unique supply chain. Excellent supply chain management is one of reasons that makes our provide high quality but reasonable price products.
