China New Truck Cargo Transport Semi Trailer 10 Wheeler Wing Van

Basic Info

Model NO.	Wing open semi trailer
Wheel Base	1310
Tread	1820mm
Grade	Heavy Duty
Independent Suspension Type	Mechanical Suspension
Shape	Van-type
Axle Number	2 / 3 / 4
Tire Number	8 / 12 / 16
Self-dumping	Not Self-dumping
ABS Anti-lock Braking System	No ABS Anti-lock Braking System
Material	Steel
Condition	New
Transport Package	Bulk Shipping
Specification	13750*2550*3650
Trademark	YONGCHAO
Origin	China Shandong
HS Code	87163910
Production Capacity	3000pieces Per Year

Product Description

China New Truck Cargo Transport Semi Trailer 10 Wheeler Wing Van

Product Description

Features:1. Usage: items such as auto parts, paper, household appliances, clothing, chemical, drinks, food…2. Rain proof, dust proof, sunscreen, guard against theft, corrosion resistance.3. Load and unload 2 sides, high efficiency, less manpower, save cost.

Product Parameters

China New Truck Cargo Transport Semi Trailer 10 Wheeler Wing Van

Overall Dimension(L*W*H)	13750*2550*3650
60Tare Weight	6000KG
Loading Weight	10-20 Ton
Main beam	Material: Q345B fabricated carbon steel;Type: straight type;Height: 480mm;Upper plate: 14mm:Bottom plate: 16mmMiddle plate:8mmProcess: welded by automatic submerged-acr
cross beam	10# C type: Q235
Twist lock	12 units
King pin	50#
Axle	Brand: Xinya; Capacity: 13T16P QTY: 3 units
Tyre	Brand: Linglong;Type: 12R22.5-18PR: double mounted:QTY: 12 units
Rim	22.5*9.0-14. 12 units or 6 units
Landing gear	28T total Lifting capacity and 50T static capacity;double speed;large pad feet;
Suspension	Mechanical system with beams equaliser
Leaf spring	Germany type;Qty: 90mm*13mm*10+10+10 layers
Brake system	Type: Dual line braking systemBrake air chamber: 6 in total, T30/30*4 + T30*2Air tank: 40L*2 unit ABS: none
Electric system	24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc.

Detailed Photos

FUNCTIONS YOU NEED, FUNCTIONS WE HAVE!!!

Company Profile

XINYA have been in truck trailer field for more than 20 years.



Our products are famous in aftermarket.We've export to Europe, South America, South Africa and Southeast Asia;We've passed ISO9001:2000 & BV & SGS & CCC certificates;We've set up unified technical departments and testing standards;

XINYA Workshop

We've invested in trailer parts (axle, suspension, fifth wheel, kingpin, landing gear, twist lock etc) ;We've take part in international exhibitions;Multiple production lines, able produce multiple types truck trailers and spare parts;



XINYA IS THE SOLE COATING FACTORY IN TRUCK TRAILER FIELD IN CHINA!!!

Production Lines
Production Lines

Recommend Products

Plenty trucks and trailers for your choice!!!
Plenty trucks and trailers for your choice!!!

We can produce goods according to customers' requests or drawings;Short delivery & Safe packing;Small order quantity is acceptable;

More details for these trucks, please feel free to contact us!!!
